Discover our Small Format Graphic OLED Displays

Discover our KD017PWIOL003, 1.71” and KD022PWSOL037, 2.23” 128x32 Graphic OLED Displays

Finding the perfect balance between performance, versatility, and compact design is crucial for today’s OEM products. Introducing our latest offerings: the KD017PWIOL003 and KD022PWSOL037 OLED graphic displays. These 1.71″ and 2.23″ modules are designed to bring the cutting-edge potential of OLED technology to a wide range of applications. With sharp graphics, enhanced visibility, and robust reliability, these displays are the ideal solution for meeting the diverse demands of modern electronic designs.

Unleash the potential of OLED technology with these dynamic, compact yet powerful graphic display modules designed to meet the diverse application needs of today’s OEM products.

Compact and Powerful

Both the 1.71” and 2.23” OLED screes feature a 128 x 32 dot resolution, which delivers sharp graphics in a compact design. Their 55.02 x 13.10 and 42.22 x 10.54 active areas make them ideal for space-constrained applications.

Versatile Interface Options

Equipped with a built-in industry standard Solomon Systech SSD1305 & SSD1312 drivers the modules support SPI and I2C interfaces on the 2.23” and I2C on the 1.71”, ensuring ease of interfacing and integration into various electronic designs without compromising performance.

Enhanced Visibility and Contrast

The modules feature the on-trend white colour and deliver a 120nit brightness with high contrast ratios of up to 2000:1, near on 180° degree viewing angles and a free viewing direction ensures excellent visibility at all angles in all lighting conditions both indoors and outdoors.

Simple Integration

A single 3.3V power supply simplifies your power circuit design, plus with the modules COB PCB design, mounting within your application is via for screw holes, reducing the need for a customised display carrier often associated with the integration of COG versions.

Reliability in Harsh Environments

OLED by nature has a wide operating temperature range and will happily operate down at -40C and up at +70C and supports high humidity operation of 90%RH.

Ideal for Diverse Applications

From industrial to medical instruments to consumer electronics, OLED is the ideal, high performance display solution, giving designers the opportunity to create vibrant eye-catching text and graphic content.

Whether you’re developing industrial equipment, medical instruments, or consumer electronics, the KD017PWIOL003 and KD022PWSOL037 OLED displays offer the perfect combination of compact size, powerful performance, and exceptional visual quality. With their ease of integration, wide operating temperature range, and versatile interface options, these modules provide a reliable and dynamic display solution for a variety of applications. Explore the potential of OLED technology with our latest graphic displays and elevate your designs to new heights.
